Unbraided Flexible Hose for fire sprinkler flexible connection applications

Product Features (Specifications – Plain English List)

Connection: 1″/DN25 x ½”/DN15 or ¾”/DN20, NPT Or BSPT

Hose Diameter: O.D.26.8mm / 1-1/16″

Flow Diameter: 22.5mm / 7/8″

Maximum Service Pressure: 14bars / 203psi

Maximum Ambient Temperature: 66°C / 150°F (UL)

Chat Now

Product details

Unbraided flexible hose with a straight nipple is designed for applications requiring flexible and durable fluid transfer solutions. Made from high-quality materials, this hose ensures excellent performance and reliability in various industrial, automotive, and plumbing settings.

Product Overview

Unbraided flexible hose is designed for fire sprinkler flexible connection applications. Integrated one-piece rubber structure without outer braided layer, features good flexibility, easy bending and quick on-site installation.

Comes with NPT or BSPT thread end, compatible with multiple size combinations. Strictly made per UL standard, stable pressure and temperature resistance, smooth inner bore ensures good water flow performance, ideal for ceiling concealed and exposed sprinkler piping systems.

Specifications Table (Dimensions & Parameters)

Flexible hose		UL listing data
Model	Sprinkler thread size	Max.allow.Sprinkler K-factor	Max.no. of 90°bends	Min.bending radius	EQL of 33.7mm/1” SCH40 Pipe
	DN/in.	Metric/Imprl.	n x 90°	mm /inch	meters/feet
RF-100-700	15 1/2	80/5.6	2	100	8.2/27.0
RF-100-700	20 3/4	202/14.0	2	3.9	8.5/28.0
RF-100-1000	15 1/2	80/5.6	3	100	11.3/37.0
RF-100-1000	20 3/4	202/14.0	3	3.9	12.5/41.0
RF-100-1200	15 1/2	80/5.6	3	100	14.9/49.0
RF-100-1200	20 3/4	202/14.0	3	3.9	14.3/47.0
RF-100-1500	15 1/2	80/5.6	3	100	19.2/63.0
RF-100-1500	20 3/4	202/14.0	3	3.9	19.5/64.0
RF-100-1800	15 1/2	80/5.6	4	100	23.8/78.0
RF-100-1800	20 3/4	202/14.0	4	3.9	24.4/80.0

Product Applications

Fire sprinkler system flexible connection
Ceiling mounted and concealed fire piping
Commercial buildings, office, mall, hotel fire protection
HVAC and plumbing soft connection projects

Installation and Maintenance

Choose NPT or BSPT thread to match pipe fitting
Avoid sharp bending, stretching and sharp object scratching
Do not operate over rated pressure and temperature
Regularly inspect aging, deformation and water leakage
