This malleable iron 90° reducing Elbow Fig 90R A197 NPT is manufactured in accordance with ASTM standards. It is used for 90° direction change and diameter reduction in piping systems with smooth flow transition and low flow resistance. Made of high-quality black heart malleable iron with high-temperature annealing, it features good toughness, high strength and impact resistance. With high-precision threads for tight connection and reliable sealing, it is available in black, electro-galvanized or hot-dip galvanized finish with strong corrosion resistance. Easy to install, it is widely used in water, gas, steam, fire protection and various industrial low-pressure fluid piping systems.
Class 150 Type
| SIZE | A (MM) | B(MM) | |
| 1/4”X1/8” | DN8XDN6 | 18.8 | 19.3 |
| 3/8”X1/8” | DN10XDN6 | 20.5 | 21.6 |
| 3/8”X1/4” | DN10XDN8 | 22.4 | 22.9 |
| 1/2”X1/4” | DN15XDN8 | 24.6 | 24.9 |
| 1/2”X3/8” | DN15XDN10 | 26.4 | 26.2 |
| 3/4”X1/4” | DN20XDN8 | 26.7 | 27.4 |
| 3/4”X3/8” | DN20XDN10 | 28.5 | 28.7 |
| 3/4”X1/2” | DN20XDN15 | 30.5 | 31 |
| 1”X1/4” | DN25XDN8 | 27 | 31 |
| 1”X3/8” | DN25XDN10 | 30 | 32.3 |
| 1”X1/2” | DN25XDN15 | 32 | 35.5 |
| 1”X3/4” | DN25XDN20 | 34.8 | 36.8 |
| 1-1/4”X3/8” | DN32XDN10 | 32 | 36.5 |
| 1-1/4”X1/2” | DN32XDN15 | 34 | 38.9 |
| 1-1/4”X3/4” | DN32XDN20 | 36.8 | 41.2 |
| 1-1/4”X1” | DN32XDN25 | 40.1 | 42.4 |
| 1-1/2”X1/2” | DN40XDN15 | 35 | 41.5 |
| 1-1/2”X3/4” | DN40XDN20 | 38.6 | 44.5 |
| 1-1/2”X1” | DN40XDN25 | 41.9 | 45.7 |
| 1-1/2”X1-1/4” | DN40XDN32 | 46.2 | 47.8 |
| 2”X1/2” | DN50XDN15 | 37.5 | 47.5 |
| 2”X3/4” | DN50XDN20 | 40.6 | 50 |
| 2”X1” | DN50XDN25 | 43.9 | 51.3 |
| 2”X1-1/4” | DN50XDN32 | 48.3 | 53.3 |
| 2”X1-1/2” | DN50XDN40 | 51.3 | 54.9 |
| 2-1/2”X3/4” | DN65XDN20 | 42 | 57 |
| 2-1/2”X1” | DN65XDN25 | 46 | 58.7 |
| 2-1/2”X1-1/4” | DN65XDN32 | 50.5 | 60 |
| 2-1/2”X1-1/2” | DN65XDN40 | 54.9 | 63.8 |
| 2-1/2”X2” | DN65XDN50 | 60.7 | 66 |
| 3”X3/4” | DN80XDN20 | 45 | 65 |
| 3”X1” | DN80XDN25 | 50 | 67.5 |
| 3”X1-1/4” | DN80XDN32 | 55 | 70 |
| 3”X1-1/2” | DN80XDN40 | 58 | 72 |
| 3”X2” | DN80XDN50 | 64 | 73.4 |
Class 300 Type
| SIZE | A (MM) | B(MM) | |
| 1/2”X3/8” | DN15XDN10 | 30.2 | 30.2 |
| 1”X3/4” | DN25XDN20 | 38.1 | 39.6 |
| !-1/4”X1/2” | DN32XDN15 | 36.5 | 42 |
OEM is available. We can customize the product according to your specific requirements, including logo printing and packaging design.
The MOQ is 500 pieces. For customized products with special sizes or surface treatments, the MOQ may vary.
After order confirmation and receipt of the advance payment, we will arrange production. Generally, the products can be ready for shipment within 15-20 working days. Once dispatched, we will notify you and provide all necessary documents for customs clearance.
All products are 100% new and undergo strict quality inspections, including pressure testing and dimensional checks, before delivery. We use sturdy wooden crates or cartons to ensure the products are well-protected during transportation.
Yes, we provide detailed installation instructions in English and other major languages. Our technical support team is also available for online consultation and guidance if needed.
